Command reference Menu 3. SETUP
EN 3925-0060 V207-00 MANUAL R03.doc
HeMaTech
Prüftechnik
Creating or changing a test program
In order to be able to make entries in this dialog window, you must first switch the de-
vice to edit mode with the key switch:
Turn key switch clockwise.
Write protection is disabled, entries can be made.
Make all following entries and confirm these individually by pressing the ENTER-
key. The help text depends on the version of the device.
The insertion point jumps to the next field.
Program:
Enter a number between 1 … 99.
NOTE!
If you want to create a new program, please enter a program number
that is not yet occupied.
If you want to edit a program that already exists, enter the corre-
sponding number.
Program name:
maximum 23 characters (available)
Work piece:
maximum 23 characters (available)
Operator:
maximum 23 characters (available)
Fill pressure:
ATTENTION!
With a pressure/vacuum unit do not enter a fill/test pressure of –
0.09 … 0.19 bar/ü.
You may enter a value between 0.2 … 6.00 bar, or accept the default value of
1.00 bar.
Fill pressure ON/OFF
You can switch the filling pressure to ON or OFF with the – and + keys. The default
setting is ON.
Underfill pressure:
You can enter a value between 0.2 … 6.00 bar or accept the default value of
0.80 bar.
NOTE!
Calculate the underfill pressure as in the following example:
Fill pressure F = 2.10 bar/ü
Test pressure P = 1.90 bar/ü
Underfill pressure = P – (F – P) = 1.90 – (2.10 - 1.90) = 1.70 bar/ü
