Menu 3. SETUP Command reference
EN 3925-0060 V207-00 MANUAL R03.doc
HeMaTech
Prüftechnik
Parity:
You can use the keys – and + to establish the type of parity check. The following are
available to choose from: Without, Even, Uneven.
Protocol:
You can specify the transfer protocol with the keys – and +. The following are availa-
ble to choose from: Without, XonXoff, RtsCts.
Format:
You can specify the transfer format with the keys – and +. The following are available
to choose from: Line printer, File 01, File 02 , Record and optional special formats,
such as REGISTER, REGISTER+TO, REGISTER+TO+CS.
NOTE!
The output format File is a simple possibility for the processing of
measuring results on a PC. This will only output the measuring results
of the currently running test.
The following sections contain further information to the individual
interface formats.
Once you have made and checked all entries, you can save these data.
Turn the key switch back to the vertical write protection position.
An audible signal will sound and the device saves the changed data to the RAM
memory.
The interface has been setup for the line printer output format.
Press the ESC-key to exit the menu.
NOTE!
The interface type is determined by the hardware and cannot be
changed through the program.
