ENGINE (J05E)/TROUBLESHOOTING 2–185
1. Set the starter key to the "LOCK" position.
2. Disconnect the intake air temperature sensor (intercooler outlet)
connector.
3. Use the electrical tester to measure the resistance between the
terminals of the intake air temperature sensor (intercooler outlet).
1. Make sure the boost pressure sensor hose is not clogged, rup-
tured, or cracked.
2. Make sure the pipe on the intake manifold side is not clogged.
11
Inspect the intake air temperature sensor (intercooler outlet) unit
Measurement
conditions
Tester
connections
Standard values
Starter key: LOCK
Intake air tempera-
ture sensor (inter-
cooler outlet)
THG – E2
20 C {68 F}:
7.336 – 5.794 k
50 C {122 F}:
2.435 – 1.994 k
Do the measurements meet the standard value?
Go to step 12. Replace the intake air temperature sensor
(intercooler outlet).
Perform "After-inspection work" of INFOR-
MATION section.
12
Inspect the boost pressure sensor hose.
Was any failure found?
1. Replace the boost pressure sensor hose.
2. Clean the intake manifold pipe.
Perform "After-inspection work" of INFOR-
MATION section.
Go to step 13.
To Next Page
