ENGINE (J05E)/TROUBLESHOOTING2–44
GROUP SHARING THE SENSOR GND TERMINAL
EN01H02127030602016010
ECU terminal Sensor
E76
Fuel temperature sensor
Intake air temperature sensor (intake manifold)
Common rail pressure sensor (Main)
E77 Boost sensor
E58
Exhaust gas temperature sensor 1
Engine coolant temperature sensor
Intake air temperature sensor
V46
Exhaust gas temperature sensor 2
Exhaust gas temperature sensor 3
Exhaust gas temperature sensor 4
Differential pressure sensor
V45
Accelerator sensor 1
PTO accelerator sensor
E57 Intake throttle valve position sensor 1
E56 Common rail pressure sensor (Sub)
E65 Accelerator sensor 2
