ENGINE (J05E)/TROUBLESHOOTING 2–271
1. Set the starter key to the "LOCK" position.
2. Disconnect the connector of the intake throttle valve position sen-
sor 1 connector.
3. Use the electrical tester to measure the resistance between the
terminals of the intake throttle valve position sensor 1 connector.
3
Inspect the intake throttle valve position sensor 1 unit
Measurement
conditions
Tester
connections
Standard values
Starter key: LOCK
Intake throttle
valve position
sensor 1
(1) VTA – VC
(2) VC – E2
(3) VTA – E2
(1) 180
(2) 3 k
(3) 3 k
Do the measurements meet the standard value?
Go to step 4. Replace the intake throttle valve position
sensor 1.
Perform "After-inspection work" of INFOR-
MATION section.
To Next Page
