ENGINE (J05E)/TROUBLESHOOTING 2–663
1. Set the starter key to the "LOCK" position.
2. Disconnect the intake throttle valve position sensor connector.
3. Set the starter key to the "ON" position.
4. Use the electrical tester to measure the voltage between the termi-
nals of the intake throttle valve position sensor connector.
4
Check the power supply of intake throttle valve position sensor
Measurement
conditions
Tester
connections
Standard values
Starter key: ON
Intake throttle
valve position
sensor vehicle
side connector
VC – E2
4.5 – 5.5 V
Do the measurements meet the standard value?
Go to step 5. Repair or replace the harness.
Perform "After-inspection work" of INFOR-
MATION section.
To Next Page
