9.7 Message Reference
144
(10)Measurement Settings
Set and Query Delay 2 (after applying measurement current)
Syntax
Command
:RESistance:DELay2 <Range>,<Delay 2 time>
Query
Response
:RESistance:DELay2? <Range>
<Delay 2 time>
Command
:LPResistance:DELay2 <Range>,<Delay 2 time>
Query
Response
:LPResistance:DELay2? <Range>
<Delay 2 time>
<Range> = (:RESistance) RNG100MIL/ RNG1000MIL/ RNG10/ RNG100/ RNG1000/ RNG10K/
RNG100K/ RNG1000K/ RNG10MEG/ RNG100MEG
(:LPResistance) RNG1000MIL/ RNG10/ RNG100/ RNG1000
<Delay 2 time> = 0 to 0.1 (seconds)
Example
:RES:DEL2 RNG1000MIL,0.003
:RES:DEL2? RNG10
0.005
Set and Query Integration Time (no. of power line cycles)
Syntax
Command
:RESistance:NPLCycles <Range>,<Speed>,<Integration time
(NPLC)>
Query
Response
:RESistance:NPLCycles? <Range>,<Speed>
<Integration time (NPLC)>
Command
:LPResistance:NPLCycles <Range>,<Speed>,<Integration time
(NPLC)>
Query
Response
:LPResistance:NPLCycles? <Range>,<Speed>
<Integration time (NPLC)>
<Range> = (:RESistance) RNG100MIL/ RNG1000MIL/ RNG10/ RNG100/ RNG1000/ RNG10K/
RNG100K/ RNG1000K/ RNG10MEG/ RNG100MEG
(:LPResistance) RNG1000MIL/ RNG10/ RNG100/ RNG1000
<Speed> = SLOW/ MEDium/ FAST
<Integration time (NPLC)> = 0.01 to 6
Description
Sets the integration time as an integer multiple of power line cycles (NPLC).
Note
•
For high-resistance measurements, hum noise is suppressed and stable measured values are
acquired by setting an integer multiple of power line cycles.
• When converting to seconds, values over 100 ms are set to 100 ms.
• When querying the integration time, the instrument’s internal variable is converted and output.
So in some cases, the returned value may not match the set value.
