Switching
108
4.5
VLAN
RM Web
Release
6.0
07/2010
4.5 VLAN
VLAN contains dialogs and attributes for configuring and monitoring the
VLAN function in accordance with the IEEE 802.1Q standard.
4.5.1 VLAN Global
With this dialog you can:
X display VLAN parameters
X activate/deactivate the VLAN 0 transparent mode
X activate/deactivate GVRP
X configure and display the learning mode
X reset the VLAN settings of the device to the original defaults.
Note: The device provides the VLAN with the ID 1. The VLAN with ID 1 is
always present.
Parameter Meaning
Max. VLAN ID Displays the largest possible VLAN ID (see on page 113 “VLAN Static“).
Max. supported
VLANs
Displays the maximum number of VLANs the device supports (see on
page 113 “VLAN Static“).
Number of VLANs Displays the number of configured VLANs (see on page 113 “VLAN
Static“).
Table 39: VLAN display
