Hirschmann MACH 4000 - ARP Statistics Display; ARP Table Display

Routing
RM Web L3E
Release 6.0 07/2010
6.3 ARP
141
6.3.2 ARP statistics display
6.3.3 ARP table display
Parameter Meaning
Total entry current count Current number of ARP entries in the ARP table
Total entry peak count Highest number of ARP entries in the ARP table
Static entry current count Current number of static ARP entries in the ARP table
Static entry max count Maximum possible number of static ARP entries in the ARP table
Table 52: ARP statistics
Parameter Meaning
Module Router module
Port Port to which this entry applies.
IP Address IP address of a device that responded to an ARP query to this port.
MAC address MAC address of a device that responded to an ARP query to this
port.
Type Type of entry:
– static: static ARP entry that remains even after the ARP table is
deleted.
– dynamic: Dynamic entry that is deleted from the table after the
"Age Time" if no data is received by this device during this time.
– local: IP and MAC address of the device's own port
Table 53: ARP table
