Routing
152
6.6
Routing table
RM Web
Release
6.0
07/2010
To delete a row, select the row and click on “Delete entry”.
6.6.3 Preferences
This dialog allows you to enter a default for the importance (administrative
distance) of an entry in the routing table. The smaller the value, the more
important the entry. The router automatically assigns the importance that is
entered in the preference list to a new entry in the routing table.
Note: You always assign "connected" to the smallest value for the
administrative distance.
Parameter Meaning
Destination
Network
IP address of the destination network
Destination
Mask
Network mask for the IP address of the destination network
Next Hop IP address of the next router on the path to the destination network.
Preference The importance of this entry, on the basis of which this route is considered in
selecting the best route. As a default, the dialog takes the value from the table
in the preference dialog (see on page 152 “Preferences“). A preference with
the value 255 means “cannot be reached”, i.e. the route is not used.
ID Identification number of the tracking object whereby if this object changes its
status to down, the device deletes this route from the current routing table (see
on page 150 “Current“).
Table 60: Table for static routes
