Redundancy
RM Web L3E
Release
6.0
07/2010
7.6
VRRP/HiVRRP
209
General settings
Figure 48: VRRP/HiVRRP configuration dialog
VRRP instance settings
Parameter Meaning
Function Switch the VRRP function on and off
Version Display the VRRP version
Send VRRP Master
Trap
As soon as the router takes over the VRRP master function, it sends a
master trap
Send VRRP
Authentication
Failure Trap
As soon as the router receives a VRRP message with an incorrect
authentication, it sends a VRRP authentication error trap.
Table 93: VRRP general settings
Parameter Meaning
Module Module of the device
Port Port to which this entry applies.
VRID Virtual router ID (value 1-255)
Function Switch the VRRP instances on and off
Table 94: VRRP configuration table
