Diagnostics
250
9.5
Topology Discovery
RM Web
Release
6.0
07/2010
9.5 Topology Discovery
This dialog allows you to switch on/off the topology discovery function
(LLDP). The topology table shows you the collected information for
neighboring devices. This information enables the network management
station to map the structure of your network.
The option "Show LLDP entries exclusively" allows you to reduce the number
of table entries. In this case, the topology table hides entries from devices
without active LLDP support.
Figure 62: Topology discovery
If several devices are connected to one port, for example via a hub, the table
will contain one line for each connected device.
