Security
64
2.6
IEEE 802.1X Port Authentication
RM Web
Release
6.0
07/2010
2.6.4 RADIUS Server Settings for IEEE 802.1X
Figure 21: RADIUS Server dialog
This dialog allows you to enter the data for up to three RADIUS servers.
Click on “Create entry” to open the dialog window for entering the IP
address of a RADIUS server.
Confirm the entered IP address with “OK”. This creates a new line in the
table for this RADIUS server.
In the “UDP port” column you enter the UDP port for the RADIUS server
(the default setting is 1812).
In the “Shared secret” column you enter the character string which you get
as a key from the administrator of your RADIUS server.
With “Primary server” you name this server as the first server which the
Switch should contact for port authentication queries. If this server is not
available, the device contacts the next server in the table.
