4.5 VLAN
RM Web
Release 6.0 07/2010
Note: If you selected admitOnlyVlanTagged under “Acceptable Frame
Types” and GVRP is active, you assign the value 0 to the VLAN ID in Basic
Settings:Network.
Note: Note the following:
X HIPER-Ring
Select the port VLAN ID 1 for the ring ports and deactivate “Ingress
Filtering”.
X MRP-Ring
– If the MRP-Ring configuration (see on page 167 “Configuring the
MRP-Ring“) is not assigned to a VLAN, select the port VLAN ID 1.
– If the MRP-Ring configuration (see on page 167 “Configuring the
MRP-Ring“) is assigned to a VLAN, the device automatically performs
the VLAN configuration for this port.
Parameter Meaning Possible
Values
Default Setting
Module Module of the device on which the port
is located.
Port Port to which this entry applies.
Port VLAN ID Specifies the VLAN to which the port
assigns a received untagged data
packet.
All allowed
VLAN IDs
1
Acceptable Frame
Types
Specifies whether the port may also
receive untagged data packets.
- admitAll
-
admitOnlyVla
nTagged
admitAll
Ingress Filtering Specifies whether the port evaluates
the received tags.
on, off off
GVRP - on: The device sends and receives
GVRP data packets. The device
exchanges VLAN configuration data
with other devices.
- off: The device does not send or
receive GVRP data packets. The
device does not exchange VLAN
configuration data with other devices.
on, off off
Table 45: VLAN Port dialog
