Hirschmann MACH 4000 Reference Manual

Routing
RM Web L3E
Release 6.0 07/2010
6.7 Tracking
155
Parameter Meaning
ID Identification number of this tracking object.
Active Activate/deactivate this tracking object.
Module.Port Port identification using module and port numbers of the device,
e.g. 2.1 for port one of module two.
Link up delay [s] An interface object is given the up status if the physical link holds
for longer than the delay time.
Link down delay [s] An interface object is given the down status if the physical link
interruption remains for longer than the delay time.
Send change message Activate/deactivate the sending of an alarm when the status of
this tracking object changes.
Status Displays the status of this tracking object.
Number of changes Displays the number of status changes.
Time since last change Displays the time that elapsed since the last status change.
Table 62: Parameters of a tracking object of the type Interface
Parameter Meaning
ID Identification number of this tracking object.
Active Activate/deactivate this tracking object.
IP Address IP address of the device being monitored with ping.
Module.Port Port identification using module and port numbers of the device,
e.g. 2.1 for port one of module two. If you select "auto“, the
device will automatically use the interface with the best route.
Ping interval [s] Interval between the ping requests in seconds.
Number of Lost Pings Number of lost ping responses that will result in the status down.
Number of Received Pings Number of received consecutive ping responses that will result
in the status up.
Ping timeout [ms] The time for which the device waits for a ping response before it
evaluates this as “No ping response”.
Ping TTL The TTL value (Time To Live) in the IP packet header that the
device uses to send the ping request.
Send change message Activate/deactivate the sending of an alarm when the status of
this tracking object changes.
Status Displays the status of this tracking object.
Number of changes Displays the number of status changes.
Time since last change Displays the time that elapsed since the last status change.
Table 63: Parameters of a tracking object of the type Ping
