Hirschmann MACH 4000 Reference Manual

Redundancy
RM Web L3E
Release 6.0 07/2010
7.3 Sub-Ring
173
Figure 41: Sub-Ring basic configuration
Partner
MAC
Shows the MAC address of the Sub-Ring
Manager at the other end of the Sub-Ring.
Valid MAC
address
00 00 00 00 00
00
MRP
Domain
Assign the same MRP domain name to all the
members of a Sub-Ring. If you are only using
Hirschmann devices, you can use the default
value for the MRP domain; otherwise adjust it if
necessary. With multiple Sub-Rings, all the
Sub-Rings can use the same MRP domain
name.
All permitted
MRP domain
names
255.255.255.
255.255.255.
255.255.255.
255.255.255.
255.255.255.
255
Protocol standardMRP standardMRP
Parameter Meaning Possible
Values
Default Setting
Table 72: Sub-Ring basic configuration
