Redundancy
196
7.5
Spanning Tree
RM Web
Release
6.0
07/2010
MSTI (Multiple Spanning Tree Instance) dialog tab
These MSTI tabs in the dialog allow you to manage the individual Multiple
Spanning Tree Instances. The tab is named MSTI, followed by the
number of the instance, e.g. “MSTI 2”.
Parameter Meaning Possible Values Default Setting
Frame „VLANs“ Manage the VLANs assigned to
this Multiple Spanning Tree
Instance.
Assigned VLANs List of all VLANs currently
assigned to this MSTI.
Subset of all
statically set up
VLANs.
No VLANs.
“Add VLAN” button Opens a dialog for selecting a
VLAN ID from the statically set up
VLANs of the device. Select the
desired VLAN ID and click on
“OK”.
One of the static
VLANs.
“Remove VLAN”
button
Opens a dialog for selecting a
VLAN ID. Select the desired VLAN
ID and click on “OK”.
A VLAN currently
assigned to the
MSTI
Table 88: Multiple Spanning Tree settings, MST Instance, VLANs
