Hirschmann MACH 4000 Reference Manual

Redundancy
206
7.5 Spanning Tree
RM Web
Release 6.0 07/2010
–
a
These columns show you detailed information over and above the
standard information.
For designated ports, the device displays the information for the STP-
BPDU last received by the port. This helps with the diagnosis of possible
STP problems in the network.
Parameter Meaning Possible Values Default Setting
Tab
„MSTI <ID>“
Port configuration and information
on the selected MSTI.
Port status (read
only)
Displays the STP port status with
regard to the current MSTI.
discarding,
learning,
forwarding,
disabled,
manualForwarding,
notParticipate
-
Port role (read
only)
Displays the STP port role with
regard to the current MSTI.
root, alternate,
designated,
backup, master,
disabled
-
Port path costs Enter the path costs with regard to
the current MSTI to indicate
preference for redundant paths. If
the value is 0, the Switch
automatically calculates the path
costs depending on the
transmission rate.
0 - 200.000.000 0 (automatically)
Port priority Here you enter the port priority (the
four highest bits of the port ID) with
regard to the current MSTI as a
decimal number of the highest byte
of the port ID.
16 ≤ n*16 ≤ 240 128
Received bridge
ID (read only)
Displays the remote bridge ID of
the current MSTI from which this
port last received a BPDU.
a
.
Bridge ID
(format ppppp /
mm mm mm mm mm
mm)
-
Received port ID
(read only)
Displays the port ID of the remote
bridge of the current MSTI from
which this port last received a
BPDU.
a
Port ID,
format pn nn,
with p: port priority / 16,
nnn: port No., (both
hexadecimal)
-
Received path
costs (read only)
Displays the path costs of the
remote bridge from its root port to
the root bridge of the current
MSTI.
a
.
0-200,000,000 -
Table 92: Port-related STP settings and displays, per MSTI
