Diagnostics
262
9.9
Alarms (Traps)
RM Web
Release
6.0
07/2010
The events which can be selected are:
Name Meaning
Authentication The device has rejected an unauthorized access attempt (see on page 45
“SNMPv1/v2 Access Settings“).
Link Up/Down At one port of the device, the link to another device has been established/
interrupted.
Spanning Tree The topology of the Rapid Spanning Tree has changed.
Chassis Summarizes the following events:
– The status of a supply voltage has changed (see the System dialog).
– The status of the signal contact has changed.
To take this event into account, you activate “Create trap when status
changes” in the Diagnostics:Signal Contact 1/2 dialog.
– A media module has been added or removed (only for modular devices).
- The AutoConfiguration Adapter(ACA), has been added or removed.
- The configuration on the AutoConfiguration Adapter(ACA) does not match
that in the device.
– The temperature thresholds have been exceeded/not reached.
– The receiver power status of a port with an SFP module has changed (see
dialog Dialog:Ports:SFP Modules).
– The configuration has been successfully saved in the device and in the
AutoConfiguration Adapter(ACA), if present.
– The configuration has been changed for the first time after being saved in
the device.
Redundancy The redundancy status of the ring redundancy (redundant line active/
inactive) or (for devices that support redundant ring/network coupling) the
redundant ring/network coupling (redundancy exists) has changed.
Port security On one port a data packet has been received from an unauthorized terminal
device (see the Port Security dialog).
Table 111: Trap categories
