Hirschmann MACH 4000 Reference Manual

Appendix
270
A.1 Technical Data
RM Web
Release 6.0 07/2010
A.1 Technical Data
Switching
Size of MAC address table
(incl. static filters)
8,000 (16,000 for PowerMICE and
MACH 4000)
Max. number of statically configured MAC
address filters
100
Max. number of MAC address filters learnable
via GMRP/IGMP Snooping
1.000
Max. length of over-long packets (from rel.
03.0.00)
1,552 bytes
Latency, depending on the port data rate
10,000 Mbit/s
1,000 Mbit/s
100 Mbit/s
10 Mbit/s
Layer 2: typically 3.0 µs; Layer 3: typically 3.0
µs
Layer 2: typically 3.5 µs; Layer 3: typically 4.5
µs
Layer 2: typically 4.5 µs; Layer 3: typically 5.5
µs
Layer 2: typically 19 µs; Layer 3: typically 20 µs
Max. number of static address entries 100
(in RM mode: 0 Unicast entries)
VLAN
VLAN ID 1 to 4,042 (MACH 4000: 3,966)
Number of VLANs max. 256 simultaneously per device
max. 256 simultaneously per port
Number of VLANs in GMRP in VLAN 1 max. 256 simultaneously per device
max. 256 simultaneously per port
Access Control Lists (ACLs)
a
a. Die Geräte MAR104, MAR1042, MAR1140 und MAR1142 unterstützen ACLs ab der
Software-Release 6.1.
Number of ACL entries 100
Number of possible rules 1.000
Number of rules per ACL entry 10
Number of rules per interface 20
Number of Switch queues 8
Port priorities that can be set 0-7
