Hirschmann MACH 4000 Reference Manual

Basic Settings
32
1.5 Power over ETHERNET
RM Web
Release 6.0 07/2010
The difference between the "nominal" and "reserved" power indicates how
much power is still available to the free PoE ports.
 In the “POE on” column, you can enable/disable PoE at this port.
 The “Status” column indicates the PoE status of the port.
 In the “Priority” column (MACH 4000), set the PoE priority of the port to
“low”, “high” or “critical”.
 The “Class” column shows the class of the connected device:
ClassMaximum power delivered
0: 15.4 W = state on delivery
1: 4.0 W
2: 7.0 W
3: 15.4 W
4: Reserved, treat as class 0
 The “Name” column indicates the name of the port, see
Basic settings:Port configuration.
Figure 11: Power over Ethernet dialog
