Time
RM Web L3E
Release
6.0
07/2010
3.2
PTP (IEEE 1588)
79
PTP Version 1, Port Settings
Parameter Meaning Possible Values Default Setting
Module Module number
for modular devices, otherwise 1.
Port Port to which this entry applies.
The table remains empty if the
device does not support the PTP
mode selected
PTP on Port sends/receives PTP
synchronization messages
on on
Port blocks PTP synchronization
messages.
off
PTP Burst on 2 to 8 synchronization runs take
place during the synchronization
interval. This enables faster
synchronization with a
correspondingly higher network
load.
on off
One synchronization run is
performed in a synchronization
interval.
off
PTP Status Port is in the initialization phase. initializing
A PTP protocol error was detected
on this port.
faulty
PTP function is switched off at this
port.
disabled
Port has not received any
information and is waiting for
synchronization messages.
listening
Port is in PTP pre-master mode. pre-master
Port is in PTP master mode. master
Port is in PTP passive mode. passive
Port is in PTP uncalibrated mode. uncalibrated
Port is in PTP slave mode. slave
Table 20: Port dialog version 1
