Hitachi Compute Blade 500 Series - Menu Configuration of Megaraid Webbios

Table 3-3 Menu icons
Icon at the upper left
on the window
Operation of icon
Return to the main menu.
Return to the previous window.
Finish the utility.
Temporarily stop ringing the buzzer on the disk array
controller board.
1
Display the version of MegaRAID Web BIOS.
Note:
1. This function is not supported.
2. Menu items
Menu items for MegaRAID WebBIOS are displayed. Click each item to go
to the respective menu window.
3. Logical View/Physical View
Disks or disk arrays connected to the disk array controller are displayed.
Tip: Click a disk from disks displayed in Logical View or Physical View,
and the same window is displayed as one when you select Virtual Drives >
Properties from the menu.
Select a disk array from disks displayed in Logical View, and the same
window is displayed as the one when you click Drives > Properties from the
menu.
Menu configuration of MegaRAID WebBIOS
This section describes the setting items and values for MegaRAID WebBIOS.
• In the table for each menu, default values are enclosed in << >>.
•
In the table for each menu, recommended values are enclosed in [ ].
Example:
[<<Enabled (valid)>>]/Disabled (invalid): "Enabled" is the default and also
recommended value.
[Enabled (valid)]/<<Disabled (invalid)>>: "Disabled" is the default value;
and "Enabled" is the recommended value, which requires the change.
