Configuration of SAS configuration utility
This section describes the SAS configuration utility configuration. See the
following chart.
Figure 7-1 SAS configuration utility configuration
Key operation for SAS configuration utility
This section describes how to operate the SAS configuration utility with the
keyboard.
Table 7-1 Key operation
Key Operation
[↑], [↓], [←], [→] Moves the cursor.
[Enter], [Space] Selects an item that the cursor is placed on.
Determines an item setting.
Changes values.
[Esc] Exit the current menu.
Note: You can use only the keyboard to operate this utility.
Starting SAS configuration utility
1. Start the remote console, and then power on the server blade.
Click Power >
Power On in the tool bar of the remote console.
