3Dimensions System User Guide
Chapter 4: Startup, Functional Tests, and Shutdown
MAN-05085-002 Revision 002 Page 35
DRAFT Preview Copy-Generated May 30, 2018
Table 3: C-arm Up and Down Movement
Function Functional Test
C-arm Down
Press the C-arm Down button.
x C-arm movement stops when the button is
released.
x C-arm movement stops when the C-arm reaches
the lower travel limit.
x C-arm vertical movement and rotation are
disabled when compression force is applied. A
Service Engineer can configure the lockout force
from 22 Newtons (5 pounds) to 45 Newtons (10
pounds).
