3Dimensions System User Guide
Chapter 4: Startup, Functional Tests, and Shutdown
Page 40 MAN-05085-002 Revision 002
DRAFT Preview Copy-Generated May 30, 2018
Table 8: Automatic C-arm Clockwise Rotation
Function Functional Test
Automatic Clockwise C-
arm Rotation
Press the Motor Enable button (item 1) and the
Clockwise C-arm Rotation button (item 2) at the same
time. Release the buttons. The machine beeps and the C-
arm moves automatically clockwise.
Left Panel Right Panel
