Hologic 3Dimensions - Table 6: C-Arm Rotation Switch

3Dimensions System User Guide
Chapter 4: Startup, Functional Tests, and Shutdown
Page 38 MAN-05085-002 Revision 002
DRAFT Preview Copy-Generated May 30, 2018
Table 6: C-arm Rotation Switch
Function Functional Test
C-arm Rotation Switch Push the C-arm Rotation switch away from you to move
the C-arm toward you.
Pull the C-arm Rotation switch toward you to move the
C-arm away from you.
C-arm movement stops when the switch is released.
