4.3.3 Collimation
Table 10: C-arm Collimation
Function Functional Test
Collimator Override
The Collimator Override button changes the collimation
through the different x-ray fields.
Press the Light Field Lamp button to show the x-ray field,
then press the Collimator Override button to select an x-
ray field.
Light Field Lamp
For compression paddles: Press the Light Field Lamp
button to see the x-ray field for two minutes.
For localization paddles: Press the Light Field Lamp
button to see the x-ray field for the configured amount of
time. The default time for biopsy or needle localization
paddles is ten minutes.
Press the Light Field Lamp button again to turn off the
light field lamp.
The light field lamp automatically illuminates with the
start of the Compression Down movement.
