3Dimensions System User Guide
Chapter 4: Startup, Functional Tests, and Shutdown
MAN-05085-002 Revision 002 Page 41
DRAFT Preview Copy-Generated May 30, 2018
MLO Automatic Rotation
Table 9: Automatic MLO Rotation
Function Functional Test
Automatic Tubehead
Rotation to Zero Position
Position the C-arm at an angle greater than 15 degrees.
Press the MLO Rotation button (item 1). The Tubehead
moves automatically to the zero position. The
Compression Arm stays in its angled position. Press the
MLO Rotation button again to return the Tubehead to its
original position.
Left Panel Right Panel
