Affirm Breast Biopsy Guidance System User Guide
Chapter 5: Biopsy
MAN-06411-002 Revision 003 Page 67
5. Select the number of offset target points (three, four, or five) you require around the
center target point.
Figure 56: Four Offset Target Points
Established Around Center Target Point
Note
Keep in mind that the center target point is included in the total target points. Choosing
a "four" offset, for example, generates a total of five target points.
6. Select how far the offset target points are automatically generated from the center
target point - 2 mm, 3 mm (the default), 4 mm, or 5 mm.
Figure 57: 3 mm Spacing of Offset Points
Figure 58: 5 mm Spacing of Offset Points
