User Manual
Chapter 2—System Controls and Indicators
System Power Controls
Chapter 2—System Controls and Indicators
1.0 System Power Controls
Figure 2-1: System Power Controls
Legend for Figure 2-1
1. Gantry Power Circuit Breaker
2. Emergency Off Switch (two on the Gantry, one on the Acquisition Workstation)
3. Acquisition Workstation Power Circuit Breaker
4. Computer Power Button
5. UPS Power Button
