Hologic selenia dimensions - How to Add or Remove a View; Figure 3-7: the Add View Screen

P/N MAN-01964 Revision 001 33
DRAFT
Preview copy—Generated 7/9/2010
User Manual
Chapter 3—The User Interface
The Procedure Screen
4.4 How to Add or Remove a View
1. To add a view, select the Add View button to display the Add View screen.
Note… ID indicates Implant Displaced.
2. Select the tab, then select the view. You can select a maximum of 3 View Modifiers from
the right panel of the screen.
3. Select the Add button. A thumbnail image for each view that you select appears in the
bottom of the window.
4. To remove a selected view, select the view then select the TRASH icon.
5. To remove all selected views, select the Clear button.
Figure 3-7: The Add View Screen
View Modifiers
ID = Implant Displaced
RL = Rolled Lateral
RM = Rolled Medial
RI = Rolled Inferior
RS = Rolled Superior
NP = Nipple in Profile
AC = Anterior Compression
IMF = Infra-Mammary Fold
AX = Axillary Tissue
