12 P/N MAN-01964 Revision 001
DRAFT Preview copy—Generated 7/9/2010
User Manual
Chapter 2—System Controls and Indicators
Tubestand Controls and Indicators
3.0 Tubestand Controls and Indicators
Legend for Figure2-3
1. The Rotation Angle Displays (each side)
2. The C-arm Controls (each side)
3. The Compression Device
4. The Patient Handles (each side)
5. The Emergency Off Switches (each side)
6. The Compression Handwheels
7. The Patient Face Shield
8. The Tubehead Display
9. The Footswitches
Figure 2-3: Tubestand Controls and Indicators
