10 P/N MAN-01964 Revision 001
DRAFT Preview copy—Generated 7/9/2010
User Manual
Chapter 2—System Controls and Indicators
Acquisition Workstation Controls and Display
2.0 Acquisition Workstation Controls and Display
Figure 2-2: Acquisition Workstation Controls and Displays
Legend for Figure2-2
1. Trackball
2. Scroll Wheel
3. Compression Release
4. Emergency Off Switch
5. Fingerprint Reader
6. X-ray Button (one on each side)
7. Touchscreen Display
8. Keyboard (in drawer)
9. CD/DVD Drive
10. Bar Code Reader
11. LED for Preview Display Power
12. Preview Display
