User Manual
Chapter 2—System Controls and Indicators
Acquisition Workstation Controls and Display
2.1 Keyboard
Use the keyboard in the front drawer of the Acquisition Workstation for data entry.
2.2 Bar Code Reader
Use this device for data entry from bar codes for patient or procedure records.
2.3 Acquisition Workstation Touchscreen Display
Use the Touchscreen or trackball to select items.
2.4 Preview Display
See the images on the Preview Display.
