MAINTENANCE
8.4
ThinPrep™ 5000 Processor with AutoLoader Operator’s Manual
And, the mechanisms in the filter waste area move toward the processing area to make them easy
to reach for cleaning.
Figure 8-2 Clean System
4. When you are finished cleaning, close the doors and touch the
Continue
button. The
instrument resets the mechanisms.
5. Press
Done
to return to the Admin Options screen.
The Clean System fea-
ture allows the slide
transport arm and the
vial/filter transport arm
to slide freely for
access during mainte-
nance
(Carousel is shown for
reference, not present
during cleaning.)
The mechanisms in the filter waste area
move towards the processing area
The robot arm
moves the Auto-
Loader slide grip-
per towards the
processing area.
To Next Page
