Honeywell 30 Series IP Cameras User Guide

Figure 21 Fisheye Panel

Fisheye Layout

Due to the fisheye lens’ wide coverage of 180º hemispheric and 360º panoramic views

and to manipulate the details within, the following types of layout are provided:

Figure 22 Fisheye Layout

Table 2 Fisheye Layout

Layout Display Mode Description

1O One original view

1P One panoramic view

1R One regional view

2P Two panoramic views

1P2R One panoramic and two regional views (Wall mount)

1O3R One original and three regional views

4R Four regional views
