MPA2C3 User Manual 113
a. Set the Jumperhead to the Red R-NC (Normally Closed in Reversed Door
Access Mode)
b. This is the correct setting to connect power-to-lock locking devices (such as
magnetic locks) to the output.
4. Remove the jumperhead from the FACP jumper.
Hardware activate the FACP input on the panel and unbypass the FACP input.
Note: The amber FACP LED (in use) will not turn on automatically when the FACP jumper
has been removed.

