75
Power Measurement
How to Measure Power
4 Move to <dBm>, by using the cursor key, and press ENTER.
5 Move to the [RANGE MODE] parameter and press ENTER.
6 Move to <AUTO>, by using the cursor key, and press ENTER.
7 Perform a set of measurements.
8 Determine the highest power value measured during this set of
measurements
9 Move to the Power Meter channel and press the [Details]
softkey.
10 Move to the [RANGE MODE] parameter and press ENTER.
11 Move to <MANUAL>, by using the cursor key, and press ENTER.
12 Move to the [RANGE] parameter and press ENTER.
13 Move to next highest power value relative to the power value
determined in Step 9, by using the cursor key, and press ENTER.
NOTE If−12 dBm is the highest power value measured in Step 9, then choose
−10 dBm as the [RANGE] value.
If 8 dBm is the highest power value measured in Step 9, then choose
10 dBm as the [RANGE] value.
