Figure 12 4-port 1 Gb Ethernet NIC adapter ports location
NOTE: On some 4-port 1 Gb Ethernet NIC Adapters, the faceplate labeling is incorrect,
indicating that the ports are numbered 0 through 3. The illustration above shows the corrected
label, indicating that the ports are numbered 1 through 4.
Table 11 4-port 1 Gb Ethernet NIC adapter ports description
Slot:PortPort
2:11
2:22
2:33
2:44
24 Identifying System Components and Numbering
