HPE FlexFabric 5940 SERIES Configuration Guide

153
Assign an access port to a VLAN in interface view
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter interface view.
• Enter Layer 2 Ethernet interface
view:
interface interface-type
interface-number
• Enter Layer 2 aggregate interface
view:
interface bridge-aggregation
interface-number
N/A
3. Set the port link type to
access.
port link-type access
By default, all ports are
access ports.
4. (Optional.) Assign the
access port to a VLAN.
port access vlan
vlan-id
By default, all access ports
belong to VLAN 1.
Assigning a trunk port to a VLAN
A trunk port supports multiple VLANs. You can assign it to a VLAN in interface view.
When you assign a trunk port to a VLAN, follow these restrictions and guidelines:
• To change the link type of a port from trunk to hybrid, set the link type to access first.
• To enable a trunk port to transmit packets from its PVID, you must assign the trunk port to the
PVID by using the port trunk permit vlan command.
To assign a trunk port to one or multiple VLANs:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter interface view.
• Enter Layer 2 Ethernet interface view:
interface interface-type
interface-number
• Enter Layer 2 aggregate interface view:
interface bridge-aggregation
interface-number
N/A
3. Set the port link type to
trunk.
port link-type trunk
By default, all ports are
access ports.
4. Assign the trunk port to
the specified VLANs.
port trunk permit vlan
{ vlan-id-list |
all
}
By default, a trunk port
permits only VLAN 1.
5. (Optional.) Set the
PVID for the trunk port.
port trunk pvid vlan
vlan-id
The default setting is VLAN
1.
Assigning a hybrid port to a VLAN
A hybrid port supports multiple VLANs. You can assign it to the specified VLANs in interface view.
Make sure the VLANs have been created.
When you assign a hybrid port to a VLAN, follow these restrictions and guidelines:
• To change the link type of a port from trunk to hybrid, set the link type to access first.
• To enable a hybrid port to transmit packets from its PVID, you must assign the hybrid port to the
PVID by using the port hybrid vlan command.
