HPE FlexFabric 5940 SERIES Configuration Guide

188
[DeviceC-vlan10] quit
[DeviceC] vlan 20
[DeviceC-vlan20] quit
# Configure Ten-GigabitEthernet 1/0/5 as a hybrid port, and assign it to VLANs 10 and 20 as a
tagged VLAN member.
[DeviceC] interface ten-gigabitethernet 1/0/5
[DeviceC-Ten-GigabitEthernet1/0/5] port link-type hybrid
[DeviceC-Ten-GigabitEthernet1/0/5] port hybrid vlan 10 20 tagged
[DeviceC-Ten-GigabitEthernet1/0/5] quit
Verifying the configuration
# Verify the primary VLAN configurations on Device A. The following output uses primary VLAN 10
as an example.
[DeviceA] display private-vlan 10
Primary VLAN ID: 10
Secondary VLAN ID: 11-12
VLAN ID: 10
VLAN type: Static
Private-vlan type: Primary
Route interface: Not configured
Description: VLAN 0010
Name: VLAN 0010
Tagged ports:
Ten-GigabitEthernet1/0/2
Ten-GigabitEthernet1/0/5
Untagged ports:
Ten-GigabitEthernet1/0/3
VLAN ID: 11
VLAN type: Static
Private-vlan type: Secondary
Route interface: Not configured
Description: VLAN 0011
Name: VLAN 0011
Tagged ports:
Ten-GigabitEthernet1/0/2
Ten-GigabitEthernet1/0/5
Untagged ports: None
VLAN ID: 12
VLAN type: Static
Private-vlan type: Secondary
Route interface: Not configured
Description: VLAN 0012
Name: VLAN 0012
Tagged ports:
Ten-GigabitEthernet1/0/5
Untagged ports:
