Figure 4 RADIUS packet format
Descriptions of the fields are as follows:
• The Code field (1 byte long) indicates the type of the RADIUS packet. Table 1 gives the main
values and their meanings.
Table 1 Main values of the Code field
Cod
e
Packet type Description
1 Access-Request
From the client to the server. A packet of this type includes user information
for the server to authenticate the user. It must contain the User-Name
attribute and can optionally contain the attributes of NAS-IP-Address,
User-Password, and NAS-Port.
2 Access-Accept
From the server to the client. If all attribute values included
in the
Access-Request are acceptable, the authentication succeeds, and the
server sends an Access-Accept response.
3 Access-Reject
From the server to the client. If any attribute value included
in the
Access-Request is unacceptable, the authentication fails, and the server
sends an Access-Reject response.
4 Accounting-Request
From the client to the server. A packet of this type includes user information
for the server to start or stop accounting for the user. The Acct-Status-Type
attribute in the packet indicates whether to start or stop accounting.
5
Accounting-Respons
e
From the server to the client. The server sends a packet of this type to notify
the client that it has received the Accounting-Request and has successfully
recorded the accounting information.
• The Identifier field (1 byte long) is used to match response packets with request packets and to
detect duplicate request packets. The request and response packets of the same exchange
process for the same purpose (such as authentication or accounting) have the same identifier.
• The Length field (2 bytes long) indicates the length of the entire packet (in bytes), including the
Code, Identifier, Length, Authenticator, and Attributes fields. Bytes beyond this length are
considered padding and are ignored by the receiver. If the length of a received packet is less
than this length, the packet is dropped.
• The Authenticator field (16 bytes long) is used to authenticate responses from the RADIUS
server and to encrypt user passwords. There are two types of authenticators: request
authenticator and response authenticator.
• The Attributes field (variable in length) includes authentication, authorization, and accounting
information. This field can contain multiple attributes, each with the following subfields:
 Type—Type of the attribute.
Code
Attributes
Identifier
0
7
Length
Authenticator (16bytes)
7 15 31
