174
g. Click OK.
Figure 65 Adding an IP address group
3. Add a portal device:
a. Select User Access Manager > Portal Service Management > Device from the
navigation tree to enter the portal device configuration page.
b. Click Add to enter the page shown in Figure 66.
c. Enter the device name NAS.
d. Enter the IP address of the switch's interface connected to the host.
e. Enter the key, which must be the same as that configured on the switch.
f. Set whether to enable IP address reallocation.
This example uses direct portal authentication, and therefore select No from the Reallocate
IP list.
g. Select whether to support sever heartbeat and user heartbeat functions.
In this example, select Yes for both Support Server Heartbeat and Support User
Heartbeat.
h. Click OK.
Figure 66 Adding a portal device
4. Associate the portal device with the IP address group:
