4.4.6 Setting the UL33 UPS Device Address
Prerequisites
The UL33 UPS has been powered on.
Procedure
Step 1 The default address of the UL33 UPS is 1 and does not need to be set. Fill the address in
Equipment Address when creating a UL33 UPS on the ECC500 collector.
----End
4.4.7 Setting the NetCol5000-A Device Address
Prerequisites

You have obtained the device address assigned to the NetCol5000-A.

The NetCol5000-A has been powered on.
Procedure
Step 1 Tap Settings on the NetCol5000-A home screen.
Step 2 Enter the administrator user name and password and tap on the screen.
The preset user name and password for the NetCol5000-A are respectively Admin and 000001. To
ensure access security, change the password upon first use.
Step 3 Tap Com Settings.
Step 4 Set Com address and Baud Rate.
Table 4-7 Parameter description
Parameter
Setting
Com address
Indicates the device address planned for the NetCol5000-A.
The addresses of devices connected to the same collector port
must be unique. When creating a NetCol5000-A on the
ECC500 WebUI, enter the value in Equipment Address.
Baud Rate
Retain the default value 9600.
The DataBit, StopBit, and Parity for the NetCol5000-A cannot be set on the WebUI. Their
default values are 8, 1, and None respectively.
----End
