5.2.14 (Optional) Changing the Challenge Certification Password
Prerequisites
You have obtained the IP address of the ECC500 collector as well as the user name and
password used for WebUI login.
You have prepared a PC which is in the same IP address segment as the ECC500 and
connected the PC to the ECC500 over a switch.
Context
If the ECC500 collector needs to communicate with an upstream NMS, change the challenge
certification password by performing the following steps.
Procedure
Step 1 Log in to the WebUI of the ECC500 collector.
Step 2 Change the challenge certification password.
1. Choose System Settings > Pass-through Settings.
2. Set Enable security authentication to Enable and click Submit.
3. Set New Password and Confirm password, and then click Change Password.
Reset the challenge certification password only when necessary because the resetting will
disconnect the connection between the ECC500 collector and the NMS.
Step 3 (Optional) To restore the challenge certification password to the factory default, click Reset
password.
----End
5.2.15 (Optional) Exporting and Importing a Configuration File
Prerequisites
You have obtained the ECC500 IP address as well as the user name and password for
WebUI login.
You have prepared a PC which is in the same IP address segment as the ECC500 and
connected the PC to the ECC500 over a switch.
Context
You can export parameter configurations for ECC500 A to a PC. If ECC500 B needs the same
parameter configurations, import the configuration file to ECC500 B.
The following parameters can be exported to a configuration file:
Device operating parameters in Monitoring
