5.2.5 Adding a NetCol5000-A
Prerequisites

A NetCol5000-A is connected to the ECC500. The NetCol5000-A and ECC500 have
been powered on.

You have obtained the ECC500 IP address as well as the user name and password for
WebUI login.

You have prepared a PC which is in the same IP address segment as the ECC500 and
connected the PC to the ECC500 over a switch.
Context
After a NetCol5000-A is connected to the ECC500, add the NetCol5000-A on the ECC500
WebUI.
Procedure
Step 1 Log in to the ECC500 WebUI.
Step 2 Choose Home > Equipment Manage.
Step 3 Select NetCol from the Equipment Type drop-down list box and set device parameters, as
shown in Figure 5-20. Table 5-7 describes the setting methods.
Figure 5-20 Adding a NetCol5000-A
Table 5-7 NetCol5000-A parameters
Parameter
Setting
Communication
Board Slot
Select 3 from the drop-down list box.
NOTE
The setting example indicates that the NetCol5000-A is connected to the
COM5 port of the RS485 card in slot 3 of the ECC500. If the
