The preset user name and password for the PDU8000 are respectively admin and 000001. To ensure
access security, change the password upon first use.
Step 3 Tap Communication.
Set Serial port baud rate and Serial port address.
Table 4-9 Parameter description
Parameter
Setting
Serial port baud rate
Retain the default value 9600.
Serial port address
Indicates the device address assigned to the
PDU8000. The addresses of devices
connected to a same port must be unique.
When creating a PDU8000 on the ECC500
WebUI, enter this value in Equipment
Address.
The DataBit, StopBit, and Parity for the PDU8000 cannot be set on the WebUI. Their default
values are 8, 1, and None respectively.
----End
4.4.10 Setting the ABB OTM ATS Device Address
Prerequisites

You have obtained the device address assigned to the ABB OTM ATS.

The ABB OTM ATS has been powered on.
Procedure
Step 1 On the display panel of the ABB OTM ATS, press .
Step 2 Press to move the cursor to Device Configuration.
Step 3 Press .
Step 4 Enter the password and press .
The preset password is 0001. To ensure access security, change the password upon first use.
Step 5 Press to move the cursor to Modbus.
Step 6 Press . On the Modbus parameter setting screen, set communications parameters.
