NetCol5000-A is connected to another port, set the slot number for the
connected port.
Select 5 from the drop-down list box.
NOTE
The setting example indicates that the NetCol5000-A is connected to the
COM5 port of the RS485 card in slot 3 of the ECC500. If the
NetCol5000-A is connected to another port, set the number of the
connected port.
In this example, set Equipment Address to 1. Set the actual
device address of the NetCol5000-A during operations.
The default timeout interval is 2s. Set the parameter to the required
value.
Step 4 Click Add Equipment.
----End
Follow-up Procedure
If the device addition fails, check whether the settings are consistent with the device
parameters.
5.2.6 Adding a NetCol8000-A
Prerequisites
A NetCol8000-A is connected to the ECC500. The NetCol8000-A and ECC500 have
been powered on.
You have obtained the ECC500 IP address as well as the user name and password for
WebUI login.
You have prepared a PC which is in the same IP address segment as the ECC500 and
connected the PC to the ECC500 over a switch.
Context
After a NetCol8000-A is connected to the ECC500, add the NetCol8000-A on the ECC500
WebUI.
Procedure
Step 1 Log in to the ECC500 WebUI.
Step 2 Choose Home > Equipment Manage.
Step 3 Select NetCol from the Equipment Type drop-down list box and set device parameters, as
shown in Figure 5-21. Table 5-8 describes the setting methods.
