4.4.8 Setting the NetCol8000-A Device Address
Prerequisites

You have obtained the device address assigned to the NetCol8000-A.

The NetCol8000-A has been powered on.
Procedure
Step 1 Tap Settings on the NetCol8000-A home screen.
Step 2 Enter the administrator user name and password and tap on the screen.
The preset user name and password for the NetCol8000-A are respectively Admin and 000001. To
ensure access security, change the password upon first use.
Step 3 Tap Com Settings.
Step 4 Set Com address and Baud Rate.
Table 4-8 Parameter description
Parameter
Setting
Com address
Indicates the device address planned for the NetCol8000-A.
The addresses of devices connected to the same collector port
must be unique. When creating a NetCol8000-A on the
ECC500 WebUI, enter the value in Device address.
Baud Rate
Retain the default value 9600.
The DataBit, StopBit, and Parity for the NetCol8000-A cannot be set on the WebUI. Their
default values are 8, 1, and None respectively.
----End
4.4.9 Setting the PDU8000 Device Address
Prerequisites

You have obtained the device address assigned to the PDU8000.

The PDU8000 has been powered on.
Procedure
Step 1 Tap Settings on the PDU8000 home screen.
Step 2 Enter the PDU8000 password and tap on the screen.
